Create an SQS queue that subscribes to an SNS topic.
The SAM template deploys a SNS topic and an SQS queue. The SQS queue is subscribed to the SNS topic. SNS invokes the SQS queue when new messages are available.
When messages are sent to the SNS topic, they are delivered as a JSON event payload to the SQS queue.
AWSTemplateFormatVersion: '2010-09-09'
Transform: AWS::Serverless-2016-10-31
Description: Serverless patterns - SNS to SQS (uksb-1tthgi812) (tag:sns-sqs)
Resources:
# Define the SQS queue
MySqsQueue:
Type: AWS::SQS::Queue
# Define the SNS topic
MySnsTopic:
Type: AWS::SNS::Topic
Properties:
# Subscribes the SQS queue to the SNS topic
Subscription:
- Protocol: sqs
Endpoint: !GetAtt MySqsQueue.Arn
# Policy allows SNS to publish to this SQS queue
SnsToSqsPolicy:
Type: AWS::SQS::QueuePolicy
Properties:
PolicyDocument:
Version: "2012-10-17"
Statement:
- Sid: "Allow SNS publish to SQS"
Effect: Allow
Principal:
Service: "sns.amazonaws.com"
Resource: !GetAtt MySqsQueue.Arn
Action: SQS:SendMessage
Condition:
ArnEquals:
aws:SourceArn: !Ref MySnsTopic
Queues:
- Ref: MySqsQueue
Outputs:
MySqsQueueName:
Description: SQS queue name
Value: !GetAtt MySqsQueue.QueueName
MySqsQueueArn:
Description: SQS queue ARN
Value: !GetAtt MySqsQueue.Arn
MySqsQueueURL:
Description: SQS queue URL
Value: !Ref MySqsQueue
MySnsTopicName:
Description: SNS topic name
Value: !GetAtt MySnsTopic.TopicName
MySnsTopicArn:
Description: SNS topic ARN
Value: !Ref MySnsTopic
< Back to all patterns
Visit the GitHub repo for this pattern.
Download
git clone https://github.com/aws-samples/serverless-patterns/ cd serverless-patterns/sns-sqsDeploy
sam deploy --guidedTesting
Use the AWS CLI to send a message to the SNS topic and observe the event delivered to the Lambda function:
1. Send the SNS message:
aws sns publish --topic-arn ENTER_SNS_TOPIC_ARN --subject testSubject --message testMessage.2. Retrieve the message from the SQS queue, using the queue URL from the AWS SAM deployment outputs:
aws sqs receive-message --queue-url ENTER_YOUR_QUEUE_URL.Cleanup
1. Delete the stack:
sam delete --stack-name STACK_NAME.2. Confirm the stack has been deleted:
aws cloudformation list-stacks --query "StackSummaries[?contains(StackName,'STACK_NAME')].StackStatus"
