AWS Lamda to Amazon ElastiCache integration pattern

Created with SnapAWS LambdaAmazon ElastiCache

Create a Redis Cluster in Amazon ElastiCache and read/write with a Lambda function.

Users may want to connect to ElastiCache from their core Lambda function for use cases that involve fast read-write operations and improve latency of applications.
In an application like a leader board, queue/wait-list , API rate limiting & quota management, etc. that are built on Serverless platform , the core computing Lambda function would integrate with a either Redis or Memcache on Amazon ElastiCache.
This pattern provides a quick start guide to launch a Redis cluster in Amazon ElastiCache in a defined VPC and creates a Lambda function that read writes from that cache.
Users can further modify the code in the Lambda function as per their requirements. You can configure Memcached by modifying the cdk config and change Lambda code appropriately.

import { Duration, Stack, StackProps } from 'aws-cdk-lib';
import * as iam from 'aws-cdk-lib/aws-iam';
import * as lambda from 'aws-cdk-lib/aws-lambda';
import * as ec2 from 'aws-cdk-lib/aws-ec2';
import * as redis from 'aws-cdk-lib/aws-elasticache';
import { Construct } from 'constructs';

export class LambdaElasticacheIntegrationpatternCdkStack extends Stack {
  constructor(scope: Construct, id: string, props?: StackProps) {
    super(scope, id, props);
        // defines an AWS Lambda resource roles
        const lambdarole = new iam.Role(this,'lambda-vpc-execution-role',{
          assumedBy: new iam.ServicePrincipal('lambda.amazonaws.com'),
          description: 'Lambda execution role for accessing VPC',
          managedPolicies: [
              iam.ManagedPolicy.fromAwsManagedPolicyName(
                'service-role/AWSLambdaVPCAccessExecutionRole',
              ),
          ],
        });

      //get default or any private vpc
      const defaultvpc = ec2.Vpc.fromLookup(this, 'ElastiCacheVPC', {
        vpcName: "Default", // can be configured where ElastiCache is deployed
        isDefault: true
      });

      //security group for lambda vpc access
      const lambdasecuritygroup = new ec2.SecurityGroup(this, 'LambdaVPC-SG',{
        vpc:defaultvpc,
        allowAllOutbound: true,
        description: 'Security group for lambda to access Redis'
      });

      //get predefined securitygroup
      const redissecuritygroup = new ec2.SecurityGroup(this, 'Redis-SG',{
        vpc:defaultvpc,
        allowAllOutbound: true,
        description: 'Security group for Redis'
      });
      redissecuritygroup.addIngressRule(
        ec2.Peer.securityGroupId(lambdasecuritygroup.securityGroupId),
        ec2.Port.tcp(6379),
      );


      // Get all public subnet ids, you can deploy it to privatesubnets as well
      const Subnets = defaultvpc.publicSubnets.map((subnet) => {
        return subnet.subnetId
      });

        // Create redis subnet group from subnet ids
      const redisSubnetGroup = new redis.CfnSubnetGroup(this, 'RedisSubnetGroup', {
        subnetIds: Subnets,
        description: "Subnet group for redis"
      });

      // Create Redis Cluster
    const redisCluster = new redis.CfnCacheCluster(this, 'RedisCluster', {
      autoMinorVersionUpgrade: true,
      cacheNodeType: 'cache.t2.small',
      engine: 'redis',
      numCacheNodes: 1,
      cacheSubnetGroupName: redisSubnetGroup.ref,
      clusterName: 'sample-redis' ,
      vpcSecurityGroupIds: [redissecuritygroup.securityGroupId]
    });

    // Define this redis cluster is depends on redis subnet group created first
    redisCluster.node.addDependency(redisSubnetGroup);

    // Lambda creation
    const redisaccess = new lambda.Function(this, 'Elasticache-RedisAccess', {
      runtime: lambda.Runtime.NODEJS_18_X,    // execution environment
      code: lambda.Code.fromAsset('lambda'),  // code loaded from "lambda" directory
      handler: 'index.handler',               // file is "index", function is "handler"
      role: lambdarole,
      vpc:defaultvpc,
      allowPublicSubnet: true,
      securityGroups: [lambdasecuritygroup],
      timeout: Duration.minutes(5),
      environment: {
        REDIS_PORT: redisCluster.attrRedisEndpointPort,
        REDIS_HOST: redisCluster.attrRedisEndpointAddress,
      }
    });
  }
}

< Back to all patterns


GitHub icon Visit the GitHub repo for this pattern.

Download

git clone https://github.com/aws-samples/serverless-patterns/ cd serverless-patterns/lambda-elasticache-integrationpattern-cdk

Deploy

cdk deploy


Testing

See the README.md file of GitHub repo for detailed testing instructions.

Cleanup

Delete the stack: cdk delete.
