EventBridge schedule to trigger a Step Functionsworkflow

Created with SnapScheduleStep Functionevery every day at 14:24

Simple pattern that triggers Step Functionsexecution once a day using EventBridge Scheduler with CDK and Python.

EventBridge Scheduler triggers a new Step Functionsexecution every 5 minutes.


## Copyright Amazon.com, Inc. or its affiliates. All Rights Reserved.
## SPDX-License-Identifier: MIT-0

AWSTemplateFormatVersion: '2010-09-09'
Transform: AWS::Serverless-2016-10-31
Description: Introduction to serverless for developers:part3 GitHub to Slack (uksb-1tthgi812) (tag:eventbridge-schedule-stepfunctions-sam)

##########################################################################
#  Parameters & Globals                                                  #
##########################################################################
Parameters:

Resources:
##########################################################################
#   Lambda Functions                                                      #
##########################################################################
    #  Order Manager SFN                                                   #
  GitHubTrafficTracker:
    Type: AWS::Serverless::StateMachine # More info about State Machine Resource: https://docs.aws.amazon.com/serverless-application-model/latest/developerguide/sam-resource-statemachine.html
    Properties:
      DefinitionUri: statemachine/statemachine.asl.json

  # Schedule that will run every day at 00:00 to trigger process
  GitHubTrafficTrackerSchedule:
    Type: AWS::Scheduler::Schedule
    Properties:
      Description: Schedule the runs every day to start teh workflow
      FlexibleTimeWindow:
        Mode: 'OFF'
      ScheduleExpression: 'cron(24 14 * * ? *)'
      Target:
        Arn: !GetAtt GitHubTrafficTracker.Arn
        RoleArn: !GetAtt GitHubTrafficTrackerScheduleRole.Arn

  GitHubTrafficTrackerScheduleRole:
    Type: AWS::IAM::Role
    Properties:
      AssumeRolePolicyDocument:
        Version: 2012-10-17
        Statement:
          - Effect: Allow
            Principal:
              Service:
                - scheduler.amazonaws.com
            Action:
              - sts:AssumeRole
      Policies:
        - PolicyName: invokeGitHubTrafficTrackerSFN
          PolicyDocument:
            Version: 2012-10-17
            Statement:
              - Effect: Allow
                Action:
                  - 'states:startExecution'
                Resource:
                  - !GetAtt GitHubTrafficTracker.Arn

< Back to all patterns


GitHub icon Visit the GitHub repo for this pattern.

Download

git clone https://github.com/aws-samples/serverless-patterns/ cd serverless-patterns/eventbridge-schedule-stepfunctions-sam

Deploy

sam build && sam deploy -g


Testing

See the README in the GitHub repo for detailed testing instructions.

Cleanup

Delete the stack: sam delete.
