Amazon EventBridge Schedule to Amazon Elastic Container Service

Created with SnapAmazon EventBridge SchedulerAmazon Elastic Container Service (ECS)

Creates an EventBridge schedule to invoke an Amazon Elastic Container Service task every 5 minutes

This pattern demonstrates how to invoke an Amazon Elastic Container Service (ECS) task using EventBridge Scheduler and deployed with Terraform.

terraform {
  required_providers {
    aws = {
      source  = "hashicorp/aws"
      version = ">= 4.64.0"
    }
  }
}

locals{
  region              = "REPLACE_ME_WITH_AWS_REGION"
  container_image     = "amazon/amazon-ecs-sample"
  vpc_cidr            = "REPLACE_ME_WITH_AWS_VPC_CIDRS"
  availability_zones  = "REPLACE_ME_WITH_AWS_AVAILABILITY_ZONES"
  public_subnets      = "REPLACE_ME_WITH_AWS_PUBLIC_SUBNETS"
  private_subnets     = "REPLACE_ME_WITH_AWS_PRIVATE_SUBNETS"
}

provider "aws" {
  region = "${local.region}"

}

### EventBridge schedule setup ###
resource "aws_scheduler_schedule" "serverlessland-eb-ecs-invoke-schedule" {
      name = "serverlessland-eb-ecs-invoke-schedule"
      flexible_time_window {
      mode = "OFF"
  }
    schedule_expression = "rate(5 minute)"
    target {
      arn = aws_ecs_cluster.serverlessland-ecs-test-cluster.arn
      role_arn = aws_iam_role.serverlessland-eventbridge-invoke-ecs-role.arn
      ecs_parameters {
          task_count = 1
          task_definition_arn = aws_ecs_task_definition.serverlessland-ecs-task-definition.arn
          launch_type = "FARGATE"

          network_configuration {
                subnets          = aws_subnet.prod-subnet-public-1.*.id
                assign_public_ip = true
                security_groups = [aws_security_group.prod-sg.id]

   }
  }
  }
}

output "ScheduleTargetTask" {
  value = aws_ecs_cluster.serverlessland-ecs-test-cluster.arn
  description = "The ARN of the ecs task being invoked from EventBridge Scheduler"
}
output "ScheduleName" {
  value = aws_scheduler_schedule.serverlessland-eb-ecs-invoke-schedule.name
  description = "Name of the EventBridge Schedule"
}


### VPC, Subnets and SG ###
resource "aws_vpc" "prod-vpc" {
    cidr_block = local.vpc_cidr
    enable_dns_support = "true" #gives you an internal domain name
    enable_dns_hostnames = "true" #gives you an internal host name
    instance_tenancy = "default"

    tags = {
        Name = "prod-vpc"
    }
}

resource "aws_subnet" "prod-subnet-public-1" {
    vpc_id = "${aws_vpc.prod-vpc.id}"
    count = length(local.public_subnets)
    cidr_block =  element(local.public_subnets,count.index)
    availability_zone = element(local.availability_zones,count.index)
    map_public_ip_on_launch = "true" //it makes this a public subnet
    depends_on = [aws_internet_gateway.aws-igw]
    tags = {
        Name = "prod-subnet-public-1"
        Environment = "prod"
    }
}

resource "aws_subnet" "prod-subnet-private-1" {
    vpc_id = "${aws_vpc.prod-vpc.id}"
    count = length(local.private_subnets)
    cidr_block =  element(local.private_subnets,count.index)
    availability_zone = element(local.availability_zones,count.index)
    depends_on = [aws_internet_gateway.aws-igw]
    tags = {
        Name = "prod-subnet-private-1"
        Environment = "prod"
    }
}

resource "aws_security_group" "prod-sg" {
  name   = "prod-sg"
  vpc_id = aws_vpc.prod-vpc.id
   ingress {
    from_port       = 0
    to_port         = 0
    protocol        = "-1"
    cidr_blocks      = ["0.0.0.0/0"]

  }
  egress {
    from_port        = 0
    to_port          = 0
    protocol         = "-1"
    cidr_blocks      = ["0.0.0.0/0"]
    ipv6_cidr_blocks = ["::/0"]
  }
}

### Networking ###
resource "aws_internet_gateway" "aws-igw" {
  vpc_id = aws_vpc.prod-vpc.id
  tags = {
    Name        = "prod-igw"
    Environment = "prod"
    }

}


resource "aws_route_table" "public" {
  vpc_id = aws_vpc.prod-vpc.id

  tags = {
    Name        = "prod-routing-table-public"
    Environment = "prod"

  }
}

resource "aws_route" "public" {
  route_table_id         = aws_route_table.public.id
  destination_cidr_block = "0.0.0.0/0"
  gateway_id             = aws_internet_gateway.aws-igw.id
}

resource "aws_route_table_association" "public" {
  count          = length(local.public_subnets)
  subnet_id      = element(aws_subnet.prod-subnet-public-1.*.id, count.index)
  route_table_id = aws_route_table.public.id
}


### ECS Cluster ###
resource "aws_ecs_cluster" "serverlessland-ecs-test-cluster" {
  name = "serverlessland-ecs-test-cluster"
  depends_on = [aws_internet_gateway.aws-igw]
  setting {
    name  = "containerInsights"
    value = "enabled"
  }
}

### ECS Task Definition ###
resource "aws_ecs_task_definition" "serverlessland-ecs-task-definition" {
  family                   = "serverlessland-ecs-task-definition"
  requires_compatibilities = ["FARGATE"]
  network_mode             = "awsvpc"
  cpu                      = 1024
  memory                   = 2048
  task_role_arn            = aws_iam_role.serverlessland-ecs-task-role.arn
  execution_role_arn       = aws_iam_role.serverlessland-ecs-task-execution-role.arn
  container_definitions    = <

< Back to all patterns


GitHub icon Visit the GitHub repo for this pattern.

Download

git clone https://github.com/aws-samples/serverless-patterns/ cd serverless-patterns/eventbridge-schedule-ecs-terraform

Deploy

See the GitHub repo for detailed deployment instructions.


Testing

See the GitHub repo for detailed testing instructions.

Cleanup

Delete the stack: terraform destroy

Rajdeep Banerjee

Presented by Rajdeep Banerjee

AWS Sr. Solutions Architect
